AN-22 Nuclear Weapon & Mirage IV A N°23 "AV" EB 1/93 Guyenne FAS (AdlA)
*30*

Typical long range take-off configuration with the nuclear weapon AN-22 which might force to use the two batteries of each 6 JATO rocket accelerators. The large round buried part behind the little open door corresponds to the location of the Doppler radar antenna linked to the autonomous nav/bomb system.
